Cushman Hauler® 800
| Make | Cushman |
| Model | Hauler® 800 |
| Type | Crawler Dozers |
How can we help?
Description
Overview
The most respected workers have a reputation for getting the job done day in and day out – like the dependable Hauler® 800. Available with a gas or electric powertrain, it delivers the practical power you need to knock down your to-do list.
Models
Model Table
| Hauler 800 Gas | Hauler 800 Electric | |
|---|---|---|
| Wheel Base | 65.5 in (166 cm) | 65.5 in (166.4 cm) |
| Wheel Track | 37.0 in (94 cm) Front 38.0 in (97 cm) Rear | 37 in (94 cm) Front / 38 in (96.5 cm) Rear |
| Power Source | 4-Cycle, 24.5 ci (401cc) Cylinder | 48V AC |
| Valve Train | Single Cylinder OHV | - |
| Horsepower (KW) | 13.5 hp (10.1 kW) | 4.4 HP (3.3 kW) Continuous |
| Electrical System | Starter/Generator. Solid State Reg. | 48V |
| Battery (Qty/Type) | One, 12V Maintenance Free | Six, 8V Deep Cycle |
| Battery Charger | - | 48V DC PowerWise™ QE, 120V AC, UL/CSA |
| Air Cleaner | Replaceable Dry Cartridge | - |
| Lubrication | Pressurized Oil System | - |
| Oil Filter | Spin-On | - |
| Cooling System | Air Cooled | - |
| Fuel Capacity | 5.96 Gallon (22.6 L) Tank | - |
| Speed Controller | - | 235 Amp AC Controller |
| Drive Train | Continuously Variable Transmission (CVT) | Motor Shaft Direct Drive |
| Gear Selection | Forward - Reverse | Dash-Mounted Forward-Neutral-Reverse |
| Rear Axle Ratio | 11.47: 1 (Forward) 14.35:1 (Reverse) | 16.99: 1 |
| Weight w/o Batteries | 761 lb ( 345.2 kg) | 735 lb (333.4 kg) |
| Curb Weight | 791 lb (358.8 kg) | 1101 lb (499.4 kg) |
| Outside Clearance Circle | 18.9 ft (5.8 m) | 18.9 ft (5.76 m) |
| Speed | 14 mph +/- 0.5 mph (22.5 kph +/-0.8 kph) | 14.5 mph ± 0.5 mph (23.3 kph ± 0.8 kph) |
| Suspension | Leaf Springs w/ Hydraulic Shock Absorbers | Leaf Springs w/ Hydraulic Shock Absorbers |
Specifications
- Air Cleaner: Replaceable Dry Cartridge
- Battery (Qty/Type): One, 12V Maintenance Free
- Battery Charger: -
- Bed Load Capacity: 400 lb (181.4 kg)
- Body & Finish: Injection Molded TPO (Front) /Injection Molded PP (Rear)
- Cargo Deck Capacity: 8.4 cu ft (0.24 m3)
- Cargo Deck Material: Roto-Molded Polyethylene
- Cooling System: Air Cooled
- Curb Weight: 791 lb (358.8 kg)
- Drive Train: Continuously Variable Transmission (CVT)
- Electrical System: Starter/Generator. Solid State Reg.
- Frame: Welded Steel w/ E-Shield e-coat plus DuraShield™ Powder Coat
- Fuel Capacity: 5.96 Gallon (22.6 L) Tank
- Gear Selection: Forward - Reverse
- Ground Clearance: 4.3 in (11 cm)
- Horsepower (KW): 13.5 hp (10.1 kW)
- Key or Pedal Start: Pedal
- Lubrication: Pressurized Oil System
- Oil Filter: Spin-On
- Outside Clearance Circle: 18.9 ft (5.8 m)
- Overall Height: 47 in (119.4 cm) (No Canopy) | 69.5 in (176.5 cm) (w/ Struts & Roof)
- Overall Length: 110 in (279.4 cm)
- Overall Width: 49 in (125 cm)
- Parking Brake: Self-Compensating,Single-Point Engagement
- Power Source: 4-Cycle, 24.5 ci (401cc) Cylinder
- Rear Axle Ratio: 11.47: 1 (Forward) 14.35:1 (Reverse)
- Seating Capacity: 2-Person
- Service Brake: Rear Wheel Mechanical, Self-Adjusting Drum
- Speed: 14 mph +/- 0.5 mph (22.5 kph +/-0.8 kph)
- Standard Color: Patriot Blue, Forest Green
- Steering: Self-Compensating Rack & Pinion
- Suspension: Leaf Springs w/ Hydraulic Shock Absorbers
- Tires: 18 x 8.5- 8 (6 Ply-rated)
- Towing Capacity: 900 lb (408.2 kg)
- Transaxle: Differential w/ Helical Gears
- Valve Train: Single Cylinder OHV
- Vehicle Load Capacity: 800 lb (362 kg)
- Weight w/o Batteries: 761 lb ( 345.2 kg)
- Wheel Base: 65.5 in (166 cm)
- Wheel Track: 37.0 in (94 cm) Front 38.0 in (97 cm) Rear
Features
- 48V AC Electric Drivetrain
- 2-Passenger Seating
- 8.4-cu-ft Cargo Bed
- 800-lb Vehicle Load Capacity
- 13.5-hp EFI Gas Engine
- 400-lb Bed Load Capacity
