Cushman Hauler® 800X ELiTE
| Make | Cushman |
| Model | Hauler® 800X ELiTE |
| Type | Crawler Dozers |
How can we help?
Description
Overview
With faster charge time, consistent performance, increased range and a lightweight footprint, Hauler 800 ELiTE vehicles are designed to maximize productivity and decrease energy costs. A highly customizable bed, functional dash and a range of options make Hauler 800 ELiTE vehicles a must have for your crew.
Models
Model Table
| Hauler 800 ELiTE | Hauler 800X ELiTE | |
|---|---|---|
| Overall Height | 47 in (120 cm) | 51 in (130 cm) |
| Ground Clearance | 4.3 in (11 cm) | 5.5 in (14 cm) |
| Curb Weight | 803 lb (364 kg) | 797 lb (361 kg) |
| Vehicle Load Capacity | 800 lb (360 kg) | 725 lb (328 kg) |
| Bed Load Capacity | 400 lb (181 kg) | 325 lb (147.4 kg) |
| Towing Capacity | 900 lb (408 kg) | 500 lb (230 kg) |
| Speed | 14.5 +/-0.5 mph (23.3 +/- 0.8 kph) | 16.5 mph ± 0.5 mph (26.5 kph ± 0.8 kph) |
| Steering | Self-Compensating Rack and Pinion | Self-Compensating Rack and Pinion |
Specifications
- Battery (Qty/Type): Two Lithium Ion 56 Volt
- Bed Load Capacity: 400 lb (181 kg)
- Body & Finish: Injection Molded TPO (front), Injection Molded PP (rear)
- Cargo Deck Capacity: 8.4 cu ft (0.24 m3)
- Curb Weight: 803 lb (364 kg)
- Drive Train: Motor Shaft Direct Drive
- Electrical System: 56-Volt
- Frame: Welded steel with E-Shield ecoat plus DuraShield™ powder coat
- Gear Selection: Dash Mount Forward-Neutral-Reverse
- Ground Clearance: 4.3 in (11 cm)
- Horsepower (KW): 11.7 HP (8.7 kW) Peak
- Key or Pedal Start: Pedal
- Outside Clearance Circle: 18.9 ft (5.76 m)
- Overall Height: 47 in (120 cm)
- Overall Length: 110 in (280 cm)
- Overall Width: 49 in (125 cm)
- Parking Brake: Self-compensating, Single Point Engagement
- Power Source: 56-Volt AC Drive
- Rear Axle Ratio: 16.99:1
- Seating Capacity: 2 Person
- Service Brake: Rear Wheel Mechanical Self-adjusting Drum
- Speed: 14.5 +/-0.5 mph (23.3 +/- 0.8 kph)
- Standard Color: Forest Green or Patriot Blue
- Steering: Self-Compensating Rack and Pinion
- Suspension: Leaf Springs with Hydraulic Shock Absorbers
- Tires: 18 x 8.5 - 8 (6 ply rated)
- Towing Capacity: 900 lb (408 kg)
- Transaxle: Differential with Helical Gears
- Vehicle Load Capacity: 800 lb (360 kg)
- Wheel Base: 65.5 in (166 cm)
- Wheel Track: 37.0 in (94 cm) Front / 38.0 in (97 cm) Rear
Features
- 325-lb Bed Load Capacity
- 800-lb Vehicle Load Capacity
- 56V AC Lithium
- Zero Maintenance Batteries
- 8.4-cu-ft Cargo Bed
- 725-lb Vehicle Load Capacity
- 5-Year Battery Warranty
- Lightweight Footprint
- 400-lb Bed Load Capacity
- Cost Saving Efficiency
