Cushman Shuttle 4
| Make | Cushman |
| Model | Shuttle 4 |
| Type | Crawler Dozers |
How can we help?
Description
Overview
Throw your bags and supplies in the back and let's get moving. The Shuttle™ 4 offers extra space for luggage, gear and more, so you can help workers, guests and volunteers get all their stuff wherever it needs to go quickly.
Models
Model Table
| Shuttle 4 EFI Gas | Shuttle 4 Electric | |
|---|---|---|
| Body & Finish | Injection Molded TPO (Front) Steel Base Coat/Clear Coat (Rear) | Injection Molded TPO |
| Standard Color | Patriot Blue | Ivory |
| Overall Length | 135.0 in (343 cm) | 133.5 in (339 cm) |
| Overall Width | 48.5 in (123 cm) | 46.5 in (119 cm) |
| Power Source | 4-Cycle, 24.5 ci (401cc) | 72V DC |
| Valve Train | Single Cylinder OHV | - |
| Horsepower (KW) | 13.5 hp (10.1 kW) | 22.4 hp (16.7 kW) Intermittent |
| Electrical System | Starter/Generator. Solid State Reg. | 72V |
| Battery (Qty/Type) | One, 12V Maintenance Free | Six, 12V Deep Cycle |
| Battery Charger | - | 1000 Watt, 72V, 120/230V VAC UL Listed |
| Air Cleaner | Replaceable Dry Cartridge | - |
| Lubrication | Pressurized Oil System | - |
| Oil Filter | Spin-On | - |
| Cooling System | Air Cooled | - |
| Fuel Capacity | 6 Gallon (22.7 L) Tank | - |
| Speed Controller | - | 350 Amp AC |
| Drive Train | Continuously Variable Transmission (CVT) | Motor Shaft Direct Drive |
| Gear Selection | Forward - Reverse | Dash-Mounted Forward-Neutral-Reverse |
| Rear Axle Ratio | 11.47:1 (Forward) 14.35:1 (Reverse) | 17:1 |
| Weight w/o Batteries | - | 926 lb (420 kg) |
| Curb Weight | 936 lb (425 kg) | 1418 lb (643 kg) |
| Outside Clearance Circle | - | 25.5 ft (7.8 m) |
| Speed | 14 mph ± 0.5 mph (22.5 kph ± 0.8 kph) | High Speed 16.5 mph ± 0.5 mph (26.4 kph ± 0.8 kph), Low Speed 12 mph ± 0.5 mph (19.3 kph ± 0.8 kph) |
| Tires | 18 x 8.5 - 8 (4 Ply Rated) | 18 x 8.50 - 8 (4 Ply Rated) |
Specifications
- Air Cleaner: Replaceable Dry Cartridge
- Battery (Qty/Type): One, 12V Maintenance Free
- Battery Charger: -
- Bed Load Capacity: 400 lb (181 kg)
- Body & Finish: Injection Molded TPO (Front) Steel Base Coat/Clear Coat (Rear)
- Cargo Deck Capacity: 9-cu-ft (0.25 m3)
- Cargo Deck Material: Wood Stake Sides
- Cooling System: Air Cooled
- Curb Weight: 936 lb (425 kg)
- Drive Train: Continuously Variable Transmission (CVT)
- Electrical System: Starter/Generator. Solid State Reg.
- Frame: Welded Steel w/ DuraShield™ Powder Coat
- Fuel Capacity: 6 Gallon (22.7 L) Tank
- Gear Selection: Forward - Reverse
- Ground Clearance: 4.3 in (11 cm)
- Horsepower (KW): 13.5 hp (10.1 kW)
- Key or Pedal Start: Pedal
- Lubrication: Pressurized Oil System
- Oil Filter: Spin-On
- Overall Height: 48.6 in (123 cm) (w/o Roof) 72.0 in (183 cm) (w/ Struts & Roof)
- Overall Length: 135.0 in (343 cm)
- Overall Width: 48.5 in (123 cm)
- Parking Brake: Self-Compensating, Single-Point Engagement
- Power Source: 4-Cycle, 24.5 ci (401cc)
- Rear Axle Ratio: 11.47:1 (Forward) 14.35:1 (Reverse)
- Seating Capacity: 4-Person
- Service Brake: Rear Wheel Mechanical, Self-Adjusting Drum
- Speed: 14 mph ± 0.5 mph (22.5 kph ± 0.8 kph)
- Standard Color: Patriot Blue
- Steering: Self-Compensating Rack & Pinion
- Suspension: Leaf Springs w/ Hydraulic Shock Absorbers (Front) Leaf Springs w/ Hydraulic Shock Absorbers (Rear)
- Tires: 18 x 8.5 - 8 (4 Ply Rated)
- Transaxle: Differential w/ Helical Gears
- Valve Train: Single Cylinder OHV
- Vehicle Load Capacity: 1200 lb (544 kg)
- Wheel Base: 93.5 in (237 cm)
- Wheel Track: 34.2 in (87 cm) Front 38.0 in (97 cm) Rear
Features
- 4-Passenger Seating
- 9-cu-ft Cargo Deck
- 13.5-hp EFI Gas Engine
- 72V Electric Drivetrain
- 1,200-lb Vehicle Load Capacity
