Toyota Large IC Pneumatic Forklift
| Make | Toyota |
| Model | Large IC Pneumatic Forklift |
| Type | Internal Combustion |
How can we help?
Description
Overview
The Toyota Large IC Pneumatic Forklift can lift up to 17,500 lbs. and can easily navigate in gravel, dirt and asphalt. Popular on construction sites as well as in lumber yards, brick and stone distribution centers, specialized warehouses and heavy-duty manufacturing plants, this large heavy-duty forklift is engineered to be extremely durable and efficient in all conditions.
The Toyota Difference
Quality, durability, reliability and overall value are common terms our customers use to describe their Toyota forklift. And, they’re not alone. In fact, Toyota has been ranked number one in these major categories by Peerless Research Group since the inception of their annual survey!
Continued Performance
According to recent studies by Peerless Research Group, more and more forklift owners plan to keep their forklifts for 10+ years! Just like a car, truck or other motorized asset, periodic maintenance, service and upkeep is required, even under normal operating conditions, to keep your Toyota Large IC Pneumatic Forklift operating to peak performance. It is not uncommon for Toyota forklift owners to well exceed 10 years of use, as long as the forklift is properly maintained. Paired with a Planned Maintenance (PM) Plan, the Large IC Pneumatic Forklift can be an asset for your company for years to come.
Models
Large IC Pneumatic Forklift
| Model Number | Load Capacity* (lbs.) | Max. Travel Speed Full Load (MPH) | Max. Lift Speed Full Load (FPM) | Max. Gradeability Full Load (%) | Basic Right Angle Stack** (IN.) |
|---|---|---|---|---|---|
| 8FD60U | 13,500 | 11.8 | 81 | 34 | 150 |
| 8FG60U | 13,500 | 11.8 | 81 | 34 | 150 |
| 8FD70U | 15,500 | 11.8 | 81 | 30 | 152 |
| 8FG70U | 15,500 | 11.8 | 81 | 30 | 152 |
| 8FD80U | 17,500 | 11.8 | 73 | 26 | 154 |
| 8FG80U | 17,500 | 11.8 | 81 | 26 | 154 |
Specifications
- Fuel Type: Gas / LPG / Diesel Fuel Type
- Length to Forkface: 137.4 - 141.3 in
- Load Capacity: 13,500 - 17,500 lb. Load Capacity
- Overall Width: 77.4 in
- Overhead Guard Height: 90.9 in
- Travel Speed Full Load: 11.8 mph Travel Speed Full Load
Features
- Moisture resistant electric connectors
- Operator Presence Sensing System (OPSS)
- Key Lowering Interlock
- Automatic Transmission: 2 Speed
- Integrated monitoring system
- Dash-mounted instrument display
- Dual Drive Tires
- Load-sensing power steering
- Bolt-On Overhead Guard
- Cowl-mount hydraulic control levers
- Low wide-entry steps
- 4-Way adjustable vinyl full-suspension seat
- Toyota designed and built engines
- System of Active Stability (SAS)
- Toyota Built Engines: 1FS / 1KD
- 12″ dual operator assist grips
- Easy access no-tools floorboard
- FPM Lifting Speed: 81
- Exclusive QR code diagnostics
- Easy access to common service items such as filters & dipsticks
- LED headlights
- Neutral Start Safety Switch
- Controller Area Network (CAN-bus) communication
- 11.8″ diameter two-spoke steering wheel
- Air cleaner discharge valve
- Electric Horn
- Engine hood assist damper with lock device
- LCD multi-function display
- Easy lift engine hood with wide 75° opening
