Yale YA55-PT
| Make | Yale |
| Model | YA55-PT |
| Type | Pallet Truck |
How can we help?
Description
Durable, Versatile, Easy to Use Manual Hand Pallet Trucks
The Yale® YA55-PT manually operated hand pallet trucks are durable, versatile and easy to use and feature an ergonomic design that may reduce operator fatigue and downtime. The YA55-PT provides exceptional maneuverability in compact areas and the standard polyurethane wheels and rollers provide outstanding rolling ease.
Models
ModelTable
| Model | Load Capacity (lbs.) | ChassisWidth | Weight (lbs.) | Fork Length |
|---|---|---|---|---|
| YA55-PT-20.5 | 5500 | 20.5 | 180 | 48 |
| YA55-PT-27 | 5500 | 27 | 180 | 48 |
Specifications
- Capacity: 5,500 lbs
- Max Height: 7
- Max Weight: 5500 lbs
- Series Title: YA55-PT
- Type: Manual Hand Pallet Trucks
- Weight: lbs
Features
- 9" handle base
- Tandem load wheels
- Exit rollers prevent "pulling" the pallet when exiting
- Quick-lift pump units
- Handle-return spring guard
- 10 full strokes to reach maximum lift
- Articulating axle keeps load stable and acts as a shock absorber
- Powder-coat paint finish
- Nylon load wheels
- Poly/steel steer wheel
- Parking brake
- Heavy duty 1.25" thinks steel adjustable push rods
- Handle bolt designed for easy assembly and removal
- Cushioned handle providing operator comfort
- Backrests
- Grooved lever plate and fool release pedal for quick and convenient lowering option
- Rebuildable pump
- Stainless steel and galvanized trucks available
- Various fork lengths and widths
- 2 Year warranty on hydraulic unit and frame
- Entry rollers prevent "pushing" the pallet upon entry
- 2.1" thick steel c-channel
- Grease and oil fittings at all castings and pivot points
